China Crawler Excavator Operating Weight 23T

1 / 5

China Crawler Excavator Operating Weight 23T

Discover WINGS medium-tonnage crawler excavator for sale, equipped with a luxurious enclosed cabin with air conditioning for ultimate comfort. Standard features include hydraulic pilot operation, quick-attach tools, high-flow hydraulic system, and a reliable imported Yanmar engine for exceptional performance. Perfect for versatile tasks!

Send Inquiry

Product Description

⚙️

Key Features

● Model: Crawler Excavator-SH65/75.

● Operating Weight: 6,500/7,500kg.

● Product Type: Medium-sized model, enclosed cab.

● Engine: Yanmar diesel engine (original import).

● High-Flow Hydraulic System: Provides powerful and efficient performance for material handling, grading, and trenching.

● Load-Sensing Control: Adjusts hydraulic displacement to match load requirements, optimizing energy use and reducing fuel consumption.

🏗️

Applications

Construction Sites: Ideal for material handling, site preparation, and earthmoving tasks. Its compact design and powerful hydraulics make it suitable for confined spaces and heavy-duty operations.

Municipal and Utility Work: Excellent for road maintenance, utility installation, and other municipal projects requiring precise and efficient performance.

Forestry and Off-Road Applications: Its strong traction and stability allow it to perform well in forestry operations and challenging off-road conditions.

📊

Main Parameter

Specification
Category	Model Detail	Unit	SH65	SH75
Performance	Bucket Capacity	m³	0.21	0.28
	Total Weight	kg	6000	7500
	Swing Speed	rmp	0-11	0-11
	Gradeability	°	35	35
	Max.Bucket Digging Force	KN	48	56
	Engine Model	-	YANMAR 4TNV94L	YANMAR 4TNV98
	Power/Revolution Speed	KW/rmp	36.2	44.4
	System Pressure	MPa	28	27
Overall Dimension
Dimensions	LengthWidthHeight	mm	5802x1960x2420	6054x2216x2672
	Cabin Height	mm	2420	2672
	Tail Swing Radius	mm	1520	1730
Working Range
Range	Max. Digging Height	mm	5770	7023
	Max. Digging Depth	mm	3860	3898
	Max. Digging Radius	mm	5898	6128

⭐

Why This Series Stands Out?

Superior Stability on Any Terrain: Equipped with durable crawler tracks, these excavators provide excellent stability and traction on uneven, muddy, or rugged surfaces.

Powerful Performance for Mid-Sized Projects: Designed for medium-duty tasks, the SH65/75 series delivers a balanced combination of power and precision.

Energy Efficiency with Cost Savings: Advanced hydraulic systems and fuel-efficient engines minimize operating costs while maintaining top performance.

The SH65/75 is engineered to tackle mid-size projects with ease and efficiency. Equipped with durable crawler tracks, the SH-Series guarantees stability and high performance on various challenging terrains. Perfect for construction, landscaping, or infrastructure projects, this series provides a dependable and powerful excavation solution!

❓

Frequently Asked Questions

What type of engine is used in the SH65/75 models?

Both the SH65 and SH75 models are equipped with original imported Yanmar diesel engines, known for their reliability and fuel efficiency.

What are the operating weights of these excavators?

The operating weight is approximately 6,000kg for the SH65 model and 7,500kg for the SH75 model.

Is the cabin enclosed or open?

The SH65/75 series comes with a fully enclosed cab, providing a safe and comfortable environment for the operator.

How does the load-sensing control system work?

The load-sensing control system automatically adjusts hydraulic displacement to match the specific load requirements of the task, which optimizes energy use and significantly reduces fuel consumption.

What are the primary applications for the SH65/75?

They are ideal for construction site preparation, municipal road maintenance, utility installation, and forestry or off-road tasks due to their strong traction and stability.

What is the digging reach of the SH75 model?

The SH75 model features a maximum digging radius of 6,128mm and a maximum digging height of 7,023mm, making it highly versatile for various project depths and heights.
